1 to 5 Ton Industrial High Flow RO System

Water Treatment Process: Single-stage/Double-stage RO, or Double-stage RO + EDI/Polishing
Product Water Output: 5.0 tons/hour
Model: 5.0TH
Water Quality: Conductivity: 0.055 µS/cm ~ 10 µS/cm; Resistivity: 1 Ω·m ~ 18.2 Ω·m
Footprint: 8–100 m²

I. Product Overview:

1. The system adopts a configuration of pre-treatment + RO main unit to effectively remove various salts and impurities, ensuring efficient water production that meets quality standards with low operating costs.

2. Fully automated AI control system with safety features such as low water level protection and low-pressure protection.

3. Fully integrated design, compact footprint, complete configuration, easy to install and operate.

4. Imported coconut shell activated carbon with adsorption performance over 5 times better than ordinary carbon, effectively protecting the RO membrane.

5. Advanced quartz sand filtration with 3 times the effectiveness of standard media, providing multiple layers of protection for the RO membrane.

6. Imported high-precision DOW RO membranes with filtration precision up to 0.0001 micron—output water is potable.

7. Vertical booster pump with intelligent water outlet protection system for enhanced operational convenience.

II. Process Flow:

Raw Water Tank → Raw Water Booster Pump → Quartz Sand Filter → Activated Carbon Filter → Automatic Softener (Optional) → Precision Filter → Primary RO System → Pure Water Tank → Delivery Pump System (Optional)

III. Application Scope:

Suitable for industries such as electroplating, chemicals, boilers, and food processing.
